Bar Plate Heat Exchanger for Compressed Air Dryer

Metalli has been focusing on thermal management field over 10 years. Our capabilities cover a wide range that provide you one-stop solution quicker and easier.

Advantages of Metalli's plate fin heat exchangers:
• High heat transfer efficiency especially in gas treatment
• Larger heat transfer area
• Approximately 5 times lighter in weight than that of shell and tube heat exchanger.
• Able to withstand high pressure

100% customized as your requirements. Support OEM/ODM. 100% meets the standards of GB, SGS, CE.

Product name : Bar plate heat exchanger for compressed air dryer

Product Description for   Plate Fin Heat Exchanger


Core Thickness

Outer fins height

Inner fins height

Parting Sheet thickness

Max. working pressure

Working temperature


38 to 180 mm




40 bar

-10℃ to 120℃


38 to 180 mm




25 bar

0℃ to 120℃


38 to 180 mm




20 bar

-10℃ to 160℃

Metalli’s plate fin heat exchanger technologies include

Vacuum brazed and arc welding

◆ Controlled atmosphere brazed and arc welded

◆ Aluminum die casting for tanks manufacturing

◆ Aluminum extrusion for side bars manufacturing

◆ Sheet metal fabrication for shroud and other parts manufacturing

About plate fin heat exchanger

About plate fin heat exchanger

About plate fin heat exchanger

A plate-fin heat exchanger is a type of heat exchanger design that uses plates and finned chambers to transfer heat between fluids, most commonly gases. It is often categorized as a compact heat exchanger to emphasize its relatively high heat transfer surface area to volume ratio. The plate-fin heat exchanger is widely used in many industries, including the aerospace industry for its compact size and lightweight properties, as well as in cryogenics where its ability to facilitate heat transfer with small temperature differences is utilized.

Aluminum alloy plate fin heat exchangers, often referred to as Brazed Aluminum Heat Exchangers, have been used in the aircraft industry for more than 60 years and adopted into the cryogenic air separation industry around the time of the second world war and shortly afterwards into cryogenic processes in chemical plants such as Natural Gas Processing. They are also used in railway engines and motor cars. Stainless steel plate fins have been used in aircraft for 30 years and are now becoming established in chemical plant.

Metalli’s plate fin heat exchangers are widely used in below fields

●   Construction Equipment

●   Agricultural and forestry machinery

●   Green Energy

●   Railway vehicles

●   Compressor Dryers

●   Hydraulic Systems

●   Auto Industry

●   Air Separation Chemical Industry
